* Our company's products are continuously improved and optimized, and the final specifications and parameters are subject to the technical agreement
| project | Gantry machining center | GFM1613 | GFM2015 | GFM2518 | GFM3022 | GFM4025 |
| stroke | X-axis stroke | 1600 mm | 2000 mm | 2500 mm | 3000 mm | 4000 mm |
| Travel Y-axis | 1300 mm | 1500 mm | 1800 mm | 2200 mm | 2900 mm | |
| Z-axis travel | 800 mm | 800 mm | 800 mm | 1000 mm | 1000 mm | |
| Distance from spindle nose to workbench | 170-970 mm | 170-970 mm | 180-980 mm | 200-1200 mm | 300-1300 mm | |
| Distance from spindle center to Y-axis rail | 380 mm | 380 mm | 345 mm | 345 mm | 345 mm | |
| Distance from workbench to column bottom | 1000 mm | 1000 mm | 1120 mm | 1300 mm | 1400 mm | |
| Gantry width | 1400 mm | 1500 mm | 1850 mm | 2200 mm | 2550 mm | |
| Workbench | Workbench area | 1700*1200 mm | 2100*1200 mm | 2700*1500 mm | 3000*1800 mm | 4000*2100 mm |
| Maximum load of workbench | 3 T | 4 T | 5 T | 8 T | 12 T | |
| T-groove | 7*22*150 mm | 7*22*150 mm | 10*22*150mm | 9*22*150mm | 11*22*150mm | |
| principal axis | Spindle speed | 6000rpm φ190mm | 6000rpm φ190mm | 6000rpm φ190mm | 6000rpm φ190mm | 6000rpm φ190mm |
| Driving method | belt | belt | belt | belt | belt | |
| Spindle power | 18.5 KW | 18.5 KW | 18.5 KW | 22 KW | 22 KW | |
| feed | X-axis rapid feed | 10m/min | 10m/min | 8m/min | 8m/min | 8m/min |
| Y-axis rapid feed | 10m/min | 10m/min | 10m/min | 10m/min | 10m/min | |
| Z-axis rapid feed | 10m/min | 10m/min | 10m/min | 10m/min | 10m/min | |
| Tool magazine | Tool magazine form | Knife arm type | Knife arm type | Knife arm type | Knife arm type | Knife arm type |
| Knife handle form | BT 50 | BT 50 | BT 50 | BT 50 | BT 50 | |
| other | Mechanical weight | 18 T | 21 T | 25 T | 35 T | 63 T |
| Power capacity | 35 KW | 35 KW | 40 KW | 40 KW | 55 KW | |
| Atmospheric pressure source | 6-8 bar | 6-8 bar | 6-8 bar | 6-8 bar | 6-8 bar |
